Quick Detail:
1. High dielectric properties
2. Non-toxic
3. Superb electrical insulating properties
4. A wide working temperature range from 260°C down to liquid nitrogen temperatures (-260°C)
5. Lowest coefficient of friction of any known material.
6. Tremendous chemical resistance
7. Limitations: low compressive & tensile strength.
8 . Outstanding chemical resistance
9. Extremely low friction
10. Soft and formable
11. Good bearing and wear properties (bearing grade)
12. Good weathering resistance
13. Performs well at elevated temperatures
14. Virgin and recycled materials available
15. Any sizes available
Description:
Tefon resin is first molded into work-blank and then skived.
sheets are known as flexible or thin sheets.It recognized as the first fluorocarbon
material in the world and referred to as PTFE or , it is the most chemically resistant plastic known.
It has a working temperature range of minus -180°c to 260°c It also has a very low coefficient of friction
excellent thermal and electrical insulation properties and is commonly used in food contact applications.
It provides good thermal stability and has good electrical properties, but is not suitable for wear
application and is difficult to bond.
Applications:
1. Seals and gaskets
2. Valve and fitting components
3. Pump parts
4. Manifolds
5. Semiconductor equipment
6. Scientific equipment
7. Medical equipment
8. Chemical resistant tubing
9. Capacitor dielectric
10. wire isolation
11. electrical instrument isolation
Specifications:
|
Project Name |
Unit |
Result |
|
Apparent Density |
g/cm3 |
2.1 ~ 2.3 |
|
Tensile Strength |
Mpa |
≥ 14.0 |
|
Ultimate Elongation |
% |
≥ 150 |
|
Thick( mm ) |
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 15, 16, |
|
|
18, 19, 20, 22, 24, 25, 26, 28, 30, 35, 40, 50 |
||
|
Width ( mm ) |
100mm, 300mm, 1000mm, 1220mm |
|
|
length ( mm ) |
100mm, 300mm, 1000mm, 1220mm, 2000mm |
|
STOCK DIMENSION:
|
1220mm x 1220mm |
1000mm x 1000mm |
||
|
Thickness ( mm ) |
Weight |
Thickness ( mm ) |
Weight |
|
1.0mm |
3.42kg |
1.0mm |
2.30kg |
|
2.0mm |
6.85kg |
2.0mm |
4.60kg |
|
2.5mm |
8.56kg |
2.5mm |
5.75kg |
|
3.0mm |
10.27kg |
3.0mm |
6.90kg |
|
4.0mm |
13.69kg |
4.0mm |
9.20kg |
Remarks:
sheets are available in other sizes and thickness according to customer's specific
requirements.
Competitive Advantage:
1. Excellent Chemical property
2. Virgin and recycled materials available
3. Any sizes available
4. Fast Usually
